5022-474F

Part No :: 5022-474F

Manufacturer: API Delevan

Description: FIXED IND 470UH 143MA 17.9 OHM

Catalog: Fixed Inductors

DataSheet: 5022-474F PDF

Availability: 0 pieces

Current price of 5022-474F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

5022-474F Specifications

Type	Description
Series:	5022
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	-
Material - Core:	Iron
Inductance:	470 µH
Tolerance:	±1%
Current Rating (Amps):	143 mA
Current - Saturation (Isat):	-
Shielding:	Unshielded
DC Resistance (DCR):	17.9Ohm Max
Q @ Freq:	65 @ 790kHz
Frequency - Self Resonant:	3.9MHz
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	790 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.520" L x 0.250" W (13.21mm x 6.35mm)
Height - Seated (Max):	0.230" (5.80mm)

Please confirm the specifications of the products when ordering.
