MC2520Z14.7456C19XSH

Part No :: MC2520Z14.7456C19XSH

Manufacturer: KYOCERA Corporation

VIGOR # :: 2235193

Description: XTAL OSC XO 14.7456MHZ CMOS SMD

Catalog: Oscillators

DataSheet: MC2520Z14.7456C19XSH PDF

Country of origin: -

Date code: -

MC2520Z14.7456C19XSH Specifications

Type	Description
Series:	MC2520Z
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Base Resonator:	Crystal
Type:	XO (Standard)
Frequency:	14.7456 MHz
Function:	Standby (Power Down)
Output:	CMOS
Voltage - Supply:	1.71V ~ 3.63V
Frequency Stability:	±30ppm
Absolute Pull Range (APR):	-
Operating Temperature:	-40°C ~ 125°C
Spread Spectrum Bandwidth:	-
Current - Supply (Max):	6.5mA
Ratings:	AEC-Q200
Mounting Type:	Surface Mount
Package / Case:	4-SMD, No Lead
Size / Dimension:	0.098" L x 0.079" W (2.50mm x 2.00mm)
Height - Seated (Max):	0.031" (0.80mm)
