NZ2520SHA-80M-END5302A

Part No :: NZ2520SHA-80M-END5302A

Manufacturer: NDK

VIGOR # :: 2596195

Description: XTAL OSC XO 80.0000MHZ CMOS SMD

Catalog: Oscillators

DataSheet: NZ2520SHA-80M-END5302A PDF

Country of origin: -

Date code: -

NZ2520SHA-80M-END5302A Specifications

Type	Description
Series:	NZ2520SHA
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Base Resonator:	Crystal
Type:	XO (Standard)
Frequency:	80 MHz
Function:	Standby (Power Down)
Output:	CMOS
Voltage - Supply:	1.8V ~ 3.3V
Frequency Stability:	±100ppm
Absolute Pull Range (APR):	-
Operating Temperature:	-40°C ~ 125°C
Spread Spectrum Bandwidth:	-
Current - Supply (Max):	9mA
Ratings:	AEC-Q100, AEC-Q200
Mounting Type:	Surface Mount
Package / Case:	4-SMD, No Lead
Size / Dimension:	0.098" L x 0.079" W (2.50mm x 2.00mm)
