HMC511LP5ETR

Part No :: HMC511LP5ETR

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: VCO 4.8GHZ/9.6GHZ 2-13V 5X5MM

Catalog: VCOs (Voltage Controlled Oscillators)

DataSheet: HMC511LP5ETR PDF

Availability: 1032 pieces

Current price of HMC511LP5ETR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HMC511LP5ETR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Frequency Range:	4.525 ~ 5.075GHz, 9.05 ~ 10.15GHz
Frequency - Center:	4.8GHz, 9.6GHz
Voltage - Supply:	5V
Tuning Voltage (VDC):	2 V ~ 13.0 V
2nd Harmonic, Typ (dBc):	15
Icc Max:	300mA
Pushing (MHz/V):	15
Power (dBm):	8±3, 12.5±3.5
Phase Noise Typ (dBc/Hz):	-115
Operating Temperature:	-40°C ~ 85°C
Package / Case:	32-VFQFN Exposed Pad, CSP
Size / Dimension:	0.197" L x 0.197" W (5.00mm x 5.00mm)
Height:	0.039" (1.00mm)

Please confirm the specifications of the products when ordering.
