CI5203P1V00-LF

Image is for reference,
please contact us to get the real picture

Part No :: CI5203P1V00-LF

Manufacturer: CviLux

Description: 3 POS 3.96MM(.156) WIRE TO BOARD

Catalog: Rectangular Connectors - Headers, Male Pins

DataSheet: CI5203P1V00-LF PDF

Availability: 7980 pieces

Unit Price: ~~$0.19000~~

Current price of CI5203P1V00-LF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CI5203P1V00-LF Specifications

Type	Description
Series:	CI52
Package:	Bag
Part Status:	Active
Connector Type:	Header
Contact Type:	Male Pin
Pitch - Mating:	0.156" (3.96mm)
Number of Positions:	3
Number of Rows:	1
Row Spacing - Mating:	-
Number of Positions Loaded:	All
Style:	Board to Cable/Wire
Shrouding:	Shrouded - 1 Wall
Mounting Type:	Through Hole
Termination:	Solder
Fastening Type:	Locking Ramp
Contact Length - Mating:	0.303" (7.70mm)
Contact Length - Post:	0.146" (3.70mm)
Overall Contact Length:	0.575" (14.60mm)
Insulation Height:	0.370" (9.40mm)
Contact Shape:	Square
Contact Finish - Mating:	Tin
Contact Finish Thickness - Mating:	120.0µin (3.05µm)
Contact Finish - Post:	Tin
Contact Material:	Brass
Insulation Material:	Polyamide (PA46), Nylon 4/6
Features:	-
Operating Temperature:	-25°C ~ 105°C
Ingress Protection:	-
Material Flammability Rating:	UL94 V-0
Insulation Color:	Natural
Current Rating (Amps):	7A
Voltage Rating:	250VAC
