CI1104M1VR0-NH

Image is for reference,
please contact us to get the real picture

Part No :: CI1104M1VR0-NH

Manufacturer: CviLux

Description: 4 POS 1.00MM(.039) SINGLE ROW ST

Catalog: Rectangular Connectors - Headers, Male Pins

DataSheet: CI1104M1VR0-NH PDF

Availability: 5150 pieces

Unit Price: ~~$0.26000~~

Current price of CI1104M1VR0-NH is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CI1104M1VR0-NH Specifications

Type	Description
Series:	CI11
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Connector Type:	Header
Contact Type:	Male Pin
Pitch - Mating:	0.039" (1.00mm)
Number of Positions:	4
Number of Rows:	1
Row Spacing - Mating:	-
Number of Positions Loaded:	All
Style:	Board to Cable/Wire
Shrouding:	Shrouded - 4 Wall
Mounting Type:	Surface Mount
Termination:	Solder
Fastening Type:	Detent Lock
Contact Length - Mating:	0.069" (1.75mm)
Contact Length - Post:	-
Overall Contact Length:	-
Insulation Height:	0.169" (4.30mm)
Contact Shape:	Rectangular
Contact Finish - Mating:	Tin
Contact Finish Thickness - Mating:	100.0µin (2.54µm)
Contact Finish - Post:	Tin
Contact Material:	Phosphor Bronze
Insulation Material:	Polyamide (PA6T), Nylon 6T, Glass Filled, Halogen Free
Features:	Pick and Place, Solder Retention
Operating Temperature:	-25°C ~ 85°C
Ingress Protection:	-
Material Flammability Rating:	UL94 V-0
Insulation Color:	Natural
Current Rating (Amps):	1A (AC/DC)
Voltage Rating:	50VAC
