CI3103P1V00-NH

Image is for reference,
please contact us to get the real picture

Part No :: CI3103P1V00-NH

Manufacturer: CviLux

Description: 3 POS 2.54MM(.100) WIRE TO BOARD

Catalog: Rectangular Connectors - Headers, Male Pins

DataSheet: CI3103P1V00-NH PDF

Availability: 7995 pieces

Unit Price: ~~$0.16000~~

Current price of CI3103P1V00-NH is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CI3103P1V00-NH Specifications

Type	Description
Series:	CI31
Package:	Bag
Part Status:	Active
Connector Type:	Header
Contact Type:	Male Pin
Pitch - Mating:	0.100" (2.54mm)
Number of Positions:	3
Number of Rows:	1
Row Spacing - Mating:	-
Number of Positions Loaded:	All
Style:	Board to Cable/Wire
Shrouding:	Shrouded - 1 Wall
Mounting Type:	Through Hole
Termination:	Solder
Fastening Type:	Friction Lock
Contact Length - Mating:	0.295" (7.49mm)
Contact Length - Post:	0.134" (3.40mm)
Overall Contact Length:	0.559" (14.20mm)
Insulation Height:	0.453" (11.50mm)
Contact Shape:	Square
Contact Finish - Mating:	Tin
Contact Finish Thickness - Mating:	120.0µin (3.05µm)
Contact Finish - Post:	Tin
Contact Material:	Brass
Insulation Material:	Thermoplastic, Halogen Free
Features:	-
Operating Temperature:	-25°C ~ 85°C
Ingress Protection:	-
Material Flammability Rating:	UL94 V-0
Insulation Color:	Natural
Current Rating (Amps):	3A
Voltage Rating:	250VAC
