AN920036

Part No :: AN920036

Manufacturer: ZF Electronics

VIGOR # :: 3528257

Description: SENSOR ANGLE 90DEG WIRE LEADS

Catalog: Position Sensors - Angle, Linear Position Measuring

DataSheet: AN920036 PDF

Country of origin: -

Date code: -

AN920036 Specifications

Type	Description
Series:	AN9
Package:	Bulk
Part Status:	Active
For Measuring:	Angle
Technology:	Hall Effect
Rotation Angle - Electrical, Mechanical:	0° ~ 90°, Continuous
Linear Range:	-
Output:	Analog Voltage
Output Signal:	Clockwise Increase
Actuator Type:	External Magnet, Not Included
Linearity:	±3.5%
Resistance:	-
Resistance Tolerance:	-
Voltage - Supply:	5V
Mounting Type:	Chassis Mount
Termination Style:	Wire Leads
Operating Temperature:	-40°C ~ 125°C
Package / Case:	Box with Wire Leads
Supplier Device Package:	-
