Z8F022ASH020SG2156

Part No :: Z8F022ASH020SG2156

Manufacturer: Zilog / Littelfuse

VIGOR # :: 3658618

Description: IC MCU 8BIT 2KB FLASH 20SOIC

Catalog: Embedded - Microcontrollers

DataSheet: Z8F022ASH020SG2156 PDF

Country of origin: -

Date code: -

Z8F022ASH020SG2156 Specifications

Type	Description
Series:	Encore!® XP®
Package:	Tube
Part Status:	Active
Core Processor:	eZ8
Core Size:	8-Bit
Speed:	20MHz
Connectivity:	IrDA, UART/USART
Peripherals:	Brown-out Detect/Reset, LED, LVD, POR, PWM, Temp Sensor, WDT
Number of I/O:	17
Program Memory Size:	2KB (2K x 8)
Program Memory Type:	FLASH
EEPROM Size:	64 x 8
RAM Size:	512 x 8
Voltage - Supply (Vcc/Vdd):	2.7V ~ 3.6V
Data Converters:	A/D 7x10b
Oscillator Type:	Internal
Operating Temperature:	0°C ~ 70°C (TA)
Mounting Type:	Surface Mount
Package / Case:	20-SOIC (0.295", 7.50mm Width)
Supplier Device Package:	20-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
Z8F012ASH020EG2156 Match 64%	Zilog / Littelfuse IC MCU 8BIT 1KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F012ASH020EG2156
Z8F082ASH020SG2156 Match 64%	Zilog / Littelfuse IC MCU 8BIT 8KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F082ASH020SG2156
Z8F012ASH020SG2156 Match 64%	Zilog / Littelfuse IC MCU 8BIT 1KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F012ASH020SG2156
Z8F042ASH020EG2156 Match 64%	Zilog / Littelfuse IC MCU 8BIT 4KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F042ASH020EG2156
Z8F022ASH020EG2156 Match 100%	Zilog / Littelfuse IC MCU 8BIT 2KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F022ASH020EG2156
Z8F042ASH020SG2156 Match 64%	Zilog / Littelfuse IC MCU 8BIT 4KB FLASH 20SOIC	Z8F022ASH020SG2156 vs Z8F042ASH020SG2156
