SMA6863MZ LF2452

Part No :: SMA6863MZ LF2452

Manufacturer: Sanken Electric Co., Ltd.

VIGOR # :: 3923822

Description: IC MOTOR DRIVER DC 3PH 24SIP

Catalog: PMIC - Full, Half-Bridge Drivers

DataSheet: SMA6863MZ LF2452 PDF

Country of origin: -

Date code: -

SMA6863MZ LF2452 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Not For New Designs
Output Configuration:	Half Bridge (3)
Applications:	AC Motors
Interface:	Logic
Load Type:	Inductive
Technology:	Power MOSFET
Rds On (Typ):	-
Current - Output / Channel:	2.5A
Current - Peak Output:	3.75A
Voltage - Supply:	20V
Voltage - Load:	400V (Max)
Operating Temperature:	-20°C ~ 150°C (TJ)
Features:	-
Fault Protection:	Current Limiting, Over Temperature, UVLO
Mounting Type:	Through Hole
Package / Case:	24-SSIP Formed Leads
Supplier Device Package:	24-SIP, LF2452
