SIM6822M

Part No :: SIM6822M

Manufacturer: Sanken Electric Co., Ltd.

VIGOR # :: 3924026

Description: IC BRIDGE DRIVER PAR 40DIP

Catalog: PMIC - Full, Half-Bridge Drivers

DataSheet: SIM6822M PDF

Country of origin: -

Date code: -

SIM6822M Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Configuration:	Half Bridge (3)
Applications:	AC Motors
Interface:	Logic
Load Type:	Inductive
Technology:	IGBT
Rds On (Typ):	-
Current - Output / Channel:	5A
Current - Peak Output:	7.5A
Voltage - Supply:	13.5V ~ 16.5V
Voltage - Load:	400V (Max)
Operating Temperature:	-20°C ~ 100°C (TA)
Features:	Bootstrap Circuit
Fault Protection:	Current Limiting, Over Temperature, UVLO
Mounting Type:	Through Hole
Package / Case:	40-DIP (0.657", 16.70mm), 29 Leads
Supplier Device Package:	40-DIP LF2971
