MA220.LB.001

Image is for reference,
please contact us to get the real picture

Part No :: MA220.LB.001

Manufacturer: Taoglas

Description: RF ANT 700MHZ/800MHZ MOD SMA ADH

Catalog: RF Antennas

DataSheet: MA220.LB.001 PDF

Availability: 369 pieces

Unit Price: ~~$50.22000~~

Current price of MA220.LB.001 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MA220.LB.001 Specifications

Type	Description
Series:	Optimus
Package:	Bulk
Part Status:	Active
RF Family/Standard:	Cellular, General ISM, Navigation, WiFi
Frequency Group:	Wide Band
Frequency (Center/Band):	700MHz, 800MHz, 850MHz, 900MHz, 1.575GHz, 1.602GHz, 1.8GHz, 1.9GHz, 2.1GHz, 2.4GHz, 2.6GHz
Frequency Range:	698MHz ~ 960MHz, 1.575GHz ~ 1.61GHz, 1.71GHz ~ 2.17GHz, 2.4GHz ~ 2.69GHz
Antenna Type:	Module
Number of Bands:	11
VSWR:	1.92
Return Loss:	-5dB
Gain:	-1.54dBi, -0.53dBi, -0.53dBi, -1.07dBi, 3dBic, -0.1dBi, 0.72dBi, 0.89dBi, -2.4dBi, -1.59dBi
Power - Max:	5 W
Features:	Cable - 3m, LNA
Termination:	SMA Male (2)
Ingress Protection:	IP67
Mounting Type:	Adhesive
Height (Max):	0.472" (12.00mm)
Applications:	DCS, GLONASS, GPS, GSM, LTE, PCS, UMTS, WCDMA, Wi-Fi

Please confirm the specifications of the products when ordering.
