Part No :: IL 3685-3E

Manufacturer: NVE Corporation

Description: DGT ISO 2.5KV RS422/RS485 16SOIC

Catalog: Digital Isolators

Shipped from: HK warehouse

Expected Shipping Date: Oct 12 - Oct 16 2025

DataSheet: IL 3685-3E PDF

Availability: 1800 pieces

Unit Price: ~~$5.43400~~

Current price of IL 3685-3E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

IL 3685-3E Specifications

Type	Description
Series:	IsoLoop®
Package:	Tube
Part Status:	Active
Technology:	GMR (Giant Magnetoresistive)
Type:	RS422, RS485
Isolated Power:	No
Number of Channels:	3
Inputs - Side 1/Side 2:	2/1
Channel Type:	Unidirectional
Voltage - Isolation:	2500Vrms
Common Mode Transient Immunity (Min):	30kV/µs
Data Rate:	40Mbps
Propagation Delay tpLH / tpHL (Max):	30ns, 30ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	-
Voltage - Supply:	3V ~ 5.5V, 4.5V ~ 5.5V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SOIC
