HAL503S-E

Part No :: HAL503S-E

Manufacturer: TDK Micronas

VIGOR # :: 4781135

Description: MAGNETIC SWITCH LATCH SOT89B-1

Catalog: Magnetic Sensors - Switches (Solid State)

DataSheet: HAL503S-E PDF

Country of origin: -

Date code: -

HAL503S-E Specifications

Type	Description
Series:	HAL® 5xy
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Function:	Latch
Technology:	Hall Effect
Polarization:	South Pole
Sensing Range:	10mT Trip, -10mT Release
Test Condition:	25°C
Voltage - Supply:	3.8V ~ 24V
Current - Supply (Max):	4.2mA
Current - Output (Max):	20mA
Output Type:	Open Drain
Features:	Temperature Compensated
Operating Temperature:	-40°C ~ 140°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	SOT-89B-1
Package / Case:	TO-243AA, Variant
