PS2801-1-A

Part No :: PS2801-1-A

Manufacturer: CEL (California Eastern Laboratories)

VIGOR # :: 4980004

Description: OPTOISOLATOR 2.5KV TRANS 4-SSOP

Catalog: Optoisolators - Transistor, Photovoltaic Output

DataSheet: PS2801-1-A PDF

Country of origin: -

Date code: -

PS2801-1-A Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Discontinued at Digi-Key
Number of Channels:	1
Voltage - Isolation:	2500Vrms
Current Transfer Ratio (Min):	80% @ 5mA
Current Transfer Ratio (Max):	600% @ 5mA
Turn On / Turn Off Time (Typ):	6µs, 5µs
Rise / Fall Time (Typ):	3µs, 5µs
Input Type:	DC
Output Type:	Transistor
Voltage - Output (Max):	80V
Current - Output / Channel:	50mA
Voltage - Forward (Vf) (Typ):	1.1V
Current - DC Forward (If) (Max):	50 mA
Vce Saturation (Max):	300mV
Operating Temperature:	-55°C ~ 100°C
Mounting Type:	Surface Mount
Package / Case:	4-SOIC (0.173", 4.40mm Width)
Supplier Device Package:	4-SSOP
