AM40E-2415SZ-K vs JWL4024S15

This detailed comparison of AM40E-2415SZ-K and JWL4024S15 in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

AM40E-2415SZ-K

DComponents

Request For Quote

JWL4024S15

XP Power

Request For Quote

Specifications Hide identical items

Manufacturer	DComponents	XP Power
Package / Case	6-DIP Module	6-DIP Module
Description	DC DC CONVERTER 15V 40W	DC DC CONVERTER 15V 40W
In Stock	441	1 321
Mounting Type	Through Hole	Through Hole
Part Status	Active	Active
Series	AM40E-Z (40W)	JWL (40W)
Package	Tube	Tube
Type	Isolated Module	Isolated Module
Number of Outputs	1	1
Voltage - Input (Min)	18V	9V
Voltage - Input (Max)	36V	36V
Voltage - Output 1	15V	15V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	2.67A	2.67A
Power (Watts)	40 W	40 W
Voltage - Isolation	1.6 kV	1.5 kV
Applications	ITE (Commercial)	ITE (Commercial)
Features	Adjustable Output, Heat Sink, Remote On/Off	Remote On/Off, SCP
Operating Temperature	-40°C ~ 62°C (With Derating)	-40°C ~ 105°C
Efficiency	92%	89%
Size / Dimension	2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)	2.00" L x 1.00" W x 0.40" H (50.8mm x 25.4mm x 10.2mm)
Supplier Device Package	-	-
Control Features	-	Enable, Active High
Approval Agency	CE	-
Standard Number	-	62368-1
