DBS700B36 vs DBS700B48

This detailed comparison of DBS700B36 and DBS700B48 in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

DBS700B36

Cosel

Request For Quote

DBS700B48

Cosel

Request For Quote

Specifications Hide identical items

Manufacturer	Cosel	Cosel
Package / Case	21-DIP Module	21-DIP Module
Description	DC DC CONVERTER 36V	DC DC CONVERTER 48V
In Stock	97	95
Mounting Type	Through Hole	Through Hole
Part Status	Active	Active
Series	DBS (700W)	DBS (700W)
Package	-	-
Type	Isolated Module	Isolated Module
Number of Outputs	1	1
Voltage - Input (Min)	200V	200V
Voltage - Input (Max)	400V	400V
Voltage - Output 1	36V	48V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	19.5A	14.5A
Power (Watts)	-	-
Voltage - Isolation	3 kV	3 kV
Applications	ITE (Commercial)	ITE (Commercial)
Features	Remote On/Off, OCP, OTP, OVP	Remote On/Off, OCP, OTP, OVP
Operating Temperature	-40°C ~ 100°C (With Derating)	-40°C ~ 100°C (With Derating)
Efficiency	90%	91%
Size / Dimension	4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm)	4.60" L x 2.40" W x 0.50" H (116.8mm x 61.0mm x 12.7mm)
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	-	-
Standard Number	-	-
