TSR 1-4833WI vs LCW78_03-1.0

This detailed comparison of TSR 1-4833WI and LCW78_03-1.0 in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

TSR 1-4833WI

TRACO Power

Request For Quote

LCW78_03-1.0

TE Connectivity AMP Connectors

Request For Quote

Specifications Hide identical items

Manufacturer	TRACO Power	TE Connectivity AMP Connectors
Package / Case	3-SIP Module	3-SIP Module
Description	DC DC CONVERTER 3.3V 3SIP	DC-DC POL
In Stock	1 739	528
Mounting Type	Through Hole	Through Hole
Part Status	Active	Active
Series	TSR 1WI	LCW78_1.0
Package	Tube	Tube
Type	Non-Isolated PoL Module	Non-Isolated PoL Module
Number of Outputs	1	1
Voltage - Input (Min)	9V	5V
Voltage - Input (Max)	72V	72V
Voltage - Output 1	3.3V	3.3V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	1A	1A
Power (Watts)	-	3.3 W
Voltage - Isolation	-	-
Applications	ITE (Commercial)	ITE (Commercial)
Features	-	-
Operating Temperature	-40°C ~ 80°C (With Derating)	-40°C ~ 100°C (With Derating)
Efficiency	83%	81%
Size / Dimension	0.48" L x 0.34" W x 0.69" H (12.1mm x 8.6mm x 17.5mm)	0.48" L x 0.35" W x 0.69" H (12.1mm x 9.0mm x 17.5mm)
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	-	-
Standard Number	-	-
