ELXV101EC3220MH12D

Part No :: ELXV101EC3220MH12D

Manufacturer: United Chemi-Con

Description: CAP ALUM 22UF 20% 100V RADIAL

Catalog: Aluminum Electrolytic Capacitors

DataSheet: ELXV101EC3220MH12D PDF

Availability: 0 pieces

Current price of ELXV101EC3220MH12D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ELXV101EC3220MH12D Specifications

Type	Description
Series:	LXV
Package:	Tape & Box (TB)
Part Status:	Active
Capacitance:	22 µF
Tolerance:	±20%
Voltage - Rated:	100 V
ESR (Equivalent Series Resistance):	-
Lifetime @ Temp.:	3000 Hrs @ 105°C
Operating Temperature:	-55°C ~ 105°C
Polarization:	Polar
Ratings:	AEC-Q200
Applications:	Automotive
Ripple Current @ Low Frequency:	55 mA @ 120 Hz
Ripple Current @ High Frequency:	275 mA @ 100 kHz
Impedance:	530 mOhms
Lead Spacing:	0.138" (3.50mm)
Size / Dimension:	0.315" Dia (8.00mm)
Height - Seated (Max):	0.531" (13.50mm)
Surface Mount Land Size:	-
Mounting Type:	Through Hole
Package / Case:	Radial, Can

Please confirm the specifications of the products when ordering.
