SMHC2511-R82MHF

Image is for reference,
please contact us to get the real picture

Part No :: SMHC2511-R82MHF

Manufacturer: ITG Electronics, Inc.

Description: 0.82UH, 20%, 6.7MOHM, 24AMP MAX.

Catalog: Fixed Inductors

DataSheet: SMHC2511-R82MHF PDF

Availability: 10000 pieces

Unit Price: ~~$0.70000~~

Current price of SMHC2511-R82MHF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMHC2511-R82MHF Specifications

Type	Description
Series:	SMHC2511
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	-
Material - Core:	Metal
Inductance:	820 nH
Tolerance:	±20%
Current Rating (Amps):	13 A
Current - Saturation (Isat):	24A
Shielding:	Shielded
DC Resistance (DCR):	8mOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.280" L x 0.260" W (7.10mm x 6.60mm)
Height - Seated (Max):	0.118" (3.00mm)

Please confirm the specifications of the products when ordering.
