MMD-12FD-R15M-V1-RU

Image is for reference,
please contact us to get the real picture

Part No :: MMD-12FD-R15M-V1-RU

Manufacturer: Mag Layers

Description: FIXED IND 150NH 55A 0.6 MOHM SMD

Catalog: Fixed Inductors

DataSheet: MMD-12FD-R15M-V1-RU PDF

Availability: 1500 pieces

Unit Price: ~~$1.75000~~

Current price of MMD-12FD-R15M-V1-RU is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

MMD-12FD-R15M-V1-RU Specifications

Type	Description
Series:	V1
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Molded
Material - Core:	Metal
Inductance:	150 nH
Tolerance:	±20%
Current Rating (Amps):	55 A
Current - Saturation (Isat):	118A
Shielding:	Shielded
DC Resistance (DCR):	600µOhm Max
Q @ Freq:	-
Frequency - Self Resonant:	-
Ratings:	-
Operating Temperature:	-55°C ~ 125°C
Inductance Frequency - Test:	100 kHz
Features:	-
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Supplier Device Package:	-
Size / Dimension:	0.520" L x 0.508" W (13.20mm x 12.90mm)
Height - Seated (Max):	0.252" (6.40mm)

Please confirm the specifications of the products when ordering.
