SMBJ100AE3/TR13

Part No :: SMBJ100AE3/TR13

Manufacturer: Roving Networks / Microchip Technology

Description: TVS DIODE 100V 162V DO214AA

Catalog: TVS - Diodes

DataSheet: SMBJ100AE3/TR13 PDF

Availability: 0 pieces

Current price of SMBJ100AE3/TR13 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMBJ100AE3/TR13 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	100V
Voltage - Breakdown (Min):	111V
Voltage - Clamping (Max) @ Ipp:	162V
Current - Peak Pulse (10/1000µs):	3.7A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-65°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	SMBJ (DO-214AA)
