SMBJ20A-TR

Part No :: SMBJ20A-TR

Manufacturer: STMicroelectronics

Description: TVS DIODE 20V 42.8V SMB

Catalog: TVS - Diodes

DataSheet: SMBJ20A-TR PDF

Availability: 5714 pieces

Current price of SMBJ20A-TR is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMBJ20A-TR Specifications

Type	Description
Series:	SMBJ, TRANSIL™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	20V
Voltage - Breakdown (Min):	22.2V
Voltage - Clamping (Max) @ Ipp:	32.4V
Current - Peak Pulse (10/1000µs):	19.4A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	SMB (DO-214AA)
