2SD1802S-E

Part No :: 2SD1802S-E

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: TRANS NPN 50V 3A TP

Catalog: Transistors - Bipolar (BJT) - Single

DataSheet: 2SD1802S-E PDF

Availability: 9247500 pieces

Current price of 2SD1802S-E is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

2SD1802S-E Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Active
Transistor Type:	NPN
Current - Collector (Ic) (Max):	3 A
Voltage - Collector Emitter Breakdown (Max):	50 V
Vce Saturation (Max) @ Ib, Ic:	500mV @ 100mA, 2A
Current - Collector Cutoff (Max):	1µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce:	140 @ 100mA, 2V
Power - Max:	1 W
Frequency - Transition:	150MHz
Operating Temperature:	150°C (TJ)
Mounting Type:	Through Hole
Package / Case:	TO-251-3 Short Leads, IPak, TO-251AA
Supplier Device Package:	TP

Please confirm the specifications of the products when ordering.
