CSD17578Q3A

Part No :: CSD17578Q3A

Manufacturer: Texas Instruments

Description: MOSFET N-CH 30V 20A 8VSON

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: CSD17578Q3A PDF

Availability: 1458 pieces

Current price of CSD17578Q3A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CSD17578Q3A Specifications

Type	Description
Series:	NexFET™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	20A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	7.3mOhm @ 10A, 10V
Vgs(th) (Max) @ Id:	1.9V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	22.2 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	1590 pF @ 15 V
FET Feature:	-
Power Dissipation (Max):	3.2W (Ta), 37W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	8-VSONP (3x3.15)
Package / Case:	8-PowerVDFN
