0805USB-901MLC

Image is for reference,
please contact us to get the real picture

Part No :: 0805USB-901MLC

Manufacturer: COILCRAFT

Description: COMMON MODE CHOKE 2.5GHZ CUTOFF

Catalog: Common Mode Chokes

DataSheet: 0805USB-901MLC PDF

Availability: 25026 pieces

Unit Price: ~~$1.13000~~

Current price of 0805USB-901MLC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

0805USB-901MLC Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Filter Type:	Signal Line
Number of Lines:	2
Impedance @ Frequency:	-
Inductance @ Frequency:	47 nH @ 100 MHz
Frequency Coupled to Inductance @ Frequency:	-
Current Rating (Max):	500mA
DC Resistance (DCR) (Max):	170mOhm
Voltage Rating - DC:	-
Voltage Rating - AC:	-
Operating Temperature:	-40°C ~ 85°C
Ratings:	-
Approval Agency:	-
Features:	-
Mounting Type:	Surface Mount
Size / Dimension:	0.080" L x 0.050" W (2.03mm x 1.27mm)
Height (Max):	0.065" (1.65mm)
Package / Case:	0805 (2012 Metric)
