SP2502LBTG

Part No :: SP2502LBTG

Manufacturer: Wickmann / Littelfuse

Description: TVS DIODE 3.3V 20V 8SOIC

Catalog: TVS - Diodes

DataSheet: SP2502LBTG PDF

Availability: 746010000 pieces

Current price of SP2502LBTG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SP2502LBTG Specifications

Type	Description
Series:	SP2502L, SPA®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Steering (Rail to Rail)
Unidirectional Channels:	2
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	3.3V (Max)
Voltage - Breakdown (Min):	3.3V
Voltage - Clamping (Max) @ Ipp:	20V
Current - Peak Pulse (10/1000µs):	75A (8/20µs)
Power - Peak Pulse:	2100W (2.1kW)
Power Line Protection:	Yes
Applications:	Ethernet
Capacitance @ Frequency:	5pF @ 1MHz
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
