SMCG85A-HRA

Part No :: SMCG85A-HRA

Manufacturer: Wickmann / Littelfuse

Description: TVS DIODE 85V 137V DO215AB

Catalog: TVS - Diodes

DataSheet: SMCG85A-HRA PDF

Availability: 0 pieces

Current price of SMCG85A-HRA is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMCG85A-HRA Specifications

Type	Description
Series:	SMCG-HR
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	85V
Voltage - Breakdown (Min):	94.4V
Voltage - Clamping (Max) @ Ipp:	137V
Current - Peak Pulse (10/1000µs):	11A
Power - Peak Pulse:	1500W (1.5kW)
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-65°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-215AB, SMC Gull Wing
Supplier Device Package:	DO-215AB (SMCG)
