SZ1SMB12AT3G

Part No :: SZ1SMB12AT3G

Manufacturer: Wickmann / Littelfuse

Description: TVS DIODE 12V 19.9V SMB

Catalog: TVS - Diodes

DataSheet: SZ1SMB12AT3G PDF

Availability: 2861 pieces

Current price of SZ1SMB12AT3G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SZ1SMB12AT3G Specifications

Type	Description
Series:	Automotive, AEC-Q101
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	12V
Voltage - Breakdown (Min):	13.3V
Voltage - Clamping (Max) @ Ipp:	19.9V
Current - Peak Pulse (10/1000µs):	30.2A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	1245pF @ 1MHz
Operating Temperature:	-65°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	SMB

Please confirm the specifications of the products when ordering.
