SMAJ14A-Q

Part No :: SMAJ14A-Q

Manufacturer: J.W. Miller / Bourns

Description: TVS DIODE 14V 23.2V SMA

Catalog: TVS - Diodes

DataSheet: SMAJ14A-Q PDF

Availability: 4700 pieces

Current price of SMAJ14A-Q is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMAJ14A-Q Specifications

Type	Description
Series:	Automotive, AEC-Q101, SMAJ
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	14V
Voltage - Breakdown (Min):	15.6V
Voltage - Clamping (Max) @ Ipp:	23.2V
Current - Peak Pulse (10/1000µs):	17.2A
Power - Peak Pulse:	400W
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AC, SMA
Supplier Device Package:	SMA (DO-214AC)

Please confirm the specifications of the products when ordering.
