PTVS10-076C-TH

Part No :: PTVS10-076C-TH

Manufacturer: J.W. Miller / Bourns

Description: TVS DIODE 76V 140V AXIAL

Catalog: TVS - Diodes

DataSheet: PTVS10-076C-TH PDF

Availability: 0 pieces

Current price of PTVS10-076C-TH is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PTVS10-076C-TH Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Active
Type:	Zener
Unidirectional Channels:	-
Bidirectional Channels:	1
Voltage - Reverse Standoff (Typ):	76V
Voltage - Breakdown (Min):	85V
Voltage - Clamping (Max) @ Ipp:	140V
Current - Peak Pulse (10/1000µs):	10000A (10kA) (8/20µs)
Power - Peak Pulse:	-
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-40°C ~ 125°C (TJ)
Mounting Type:	Through Hole
Package / Case:	Axial, Right Angle Bend (24.15mm Center)
Supplier Device Package:	Axial
