SMBJ70AHM3_A/H

Part No :: SMBJ70AHM3_A/H

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: TVS DIODE DO214AA

Catalog: TVS - Diodes

DataSheet: SMBJ70AHM3_A/H PDF

Availability: 0 pieces

Current price of SMBJ70AHM3_A/H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMBJ70AHM3_A/H Specifications

Type	Description
Series:	Automotive, AEC-Q101, TransZorb®
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	70V
Voltage - Breakdown (Min):	77.8V
Voltage - Clamping (Max) @ Ipp:	113V
Current - Peak Pulse (10/1000µs):	5.3A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	Automotive, Telecom
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	DO-214AA (SMBJ)
