SMA5J22AHE3_A/H

Part No :: SMA5J22AHE3_A/H

Manufacturer: Vishay General Semiconductor – Diodes Division

VIGOR # :: 1948025

Description: TVS DIODE 500W DO214AC

Catalog: TVS - Diodes

DataSheet: SMA5J22AHE3_A/H PDF

Country of origin: -

Date code: -

SMA5J22AHE3_A/H Specifications

Type	Description
Series:	Automotive, AEC-Q101, TransZorb®
Package:	Tape & Reel (TR)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	22V
Voltage - Breakdown (Min):	24.4V
Voltage - Clamping (Max) @ Ipp:	35.5V
Current - Peak Pulse (10/1000µs):	14.1A
Power - Peak Pulse:	500W
Power Line Protection:	No
Applications:	Automotive
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AC, SMA
Supplier Device Package:	DO-214AC (SMA)
