SMBJ14CD-M3/I

Part No :: SMBJ14CD-M3/I

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: TVS DIODE 14V 22.9V DO214AA

Catalog: TVS - Diodes

DataSheet: SMBJ14CD-M3/I PDF

Availability: 0 pieces

Current price of SMBJ14CD-M3/I is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMBJ14CD-M3/I Specifications

Type	Description
Series:	TransZorb®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	-
Bidirectional Channels:	1
Voltage - Reverse Standoff (Typ):	14V
Voltage - Breakdown (Min):	15.8V
Voltage - Clamping (Max) @ Ipp:	22.9V
Current - Peak Pulse (10/1000µs):	26.2A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	DO-214AA (SMBJ)
