SMBJ15CD-M3/H

Part No :: SMBJ15CD-M3/H

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: TVS DIODE 15V 24V DO214AA

Catalog: TVS - Diodes

DataSheet: SMBJ15CD-M3/H PDF

Availability: 4254 pieces

Current price of SMBJ15CD-M3/H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMBJ15CD-M3/H Specifications

Type	Description
Series:	TransZorb®
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Zener
Unidirectional Channels:	-
Bidirectional Channels:	1
Voltage - Reverse Standoff (Typ):	15V
Voltage - Breakdown (Min):	17V
Voltage - Clamping (Max) @ Ipp:	24V
Current - Peak Pulse (10/1000µs):	25A
Power - Peak Pulse:	600W
Power Line Protection:	No
Applications:	General Purpose
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AA, SMB
Supplier Device Package:	DO-214AA (SMBJ)

Please confirm the specifications of the products when ordering.
