SMA5J36AHM3/H

Part No :: SMA5J36AHM3/H

Manufacturer: Vishay General Semiconductor – Diodes Division

Description: TVS DIODE DO-214AC SMA

Catalog: TVS - Diodes

DataSheet: SMA5J36AHM3/H PDF

Availability: 0 pieces

Unit Price: ~~$0.00000~~

Current price of SMA5J36AHM3/H is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

SMA5J36AHM3/H Specifications

Type	Description
Series:	Automotive, AEC-Q101, TransZorb®
Package:	Tape & Reel (TR)
Part Status:	Discontinued at Digi-Key
Type:	Zener
Unidirectional Channels:	1
Bidirectional Channels:	-
Voltage - Reverse Standoff (Typ):	36V
Voltage - Breakdown (Min):	40V
Voltage - Clamping (Max) @ Ipp:	58.1V
Current - Peak Pulse (10/1000µs):	8.6A
Power - Peak Pulse:	500W
Power Line Protection:	No
Applications:	Automotive, Telecom
Capacitance @ Frequency:	-
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Package / Case:	DO-214AC, SMA
Supplier Device Package:	DO-214AC (SMA)
