AE554L20-18PZ-LC

Part No :: AE554L20-18PZ-LC

Manufacturer: PEI-Genesis

Description: CONN RCPT HSG MALE 9POS PNL MNT

Catalog: Circular Connectors - Housings

DataSheet: AE554L20-18PZ-LC PDF

Availability: 5 pieces

Current price of AE554L20-18PZ-LC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE554L20-18PZ-LC Specifications

Type	Description
Series:	MIL-DTL-5015 Series III
Package:	Box
Part Status:	Active
Connector Type:	Receptacle Housing
Type:	For Male Pins
Number of Positions:	9
Shell Size - Insert:	20-18
Shell Size, MIL:	-
Contact Type:	Crimp
Contact Size:	12 (3), 16 (6)
Mounting Type:	Panel Mount
Mounting Feature:	Bulkhead - Front Side Nut
Fastening Type:	Threaded
Orientation:	Z
Shell Material:	Aluminum
Shell Finish:	Electroless Nickel
Housing Color:	-
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
