AE554W22-12S-LC

Part No :: AE554W22-12S-LC

Manufacturer: PEI-Genesis

Description: CONN RCPT HSG FMALE 5POS PNL MT

Catalog: Circular Connectors - Housings

DataSheet: AE554W22-12S-LC PDF

Availability: 23 pieces

Current price of AE554W22-12S-LC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE554W22-12S-LC Specifications

Type	Description
Series:	MIL-DTL-5015 Series III
Package:	Box
Part Status:	Active
Connector Type:	Receptacle Housing
Type:	For Female Sockets
Number of Positions:	5
Shell Size - Insert:	22-12
Shell Size, MIL:	-
Contact Type:	Crimp
Contact Size:	8 (2), 16 (3)
Mounting Type:	Panel Mount
Mounting Feature:	Bulkhead - Front Side Nut
Fastening Type:	Threaded
Orientation:	N (Normal)
Shell Material:	Aluminum
Shell Finish:	Cadmium
Housing Color:	Olive Drab
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
