AE776W14-9P-LC

Part No :: AE776W14-9P-LC

Manufacturer: PEI-Genesis

Description: AE7 9C 5#20, 4#12 PIN PLUG

Catalog: Circular Connectors - Housings

DataSheet: AE776W14-9P-LC PDF

Availability: 76 pieces

Current price of AE776W14-9P-LC is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE776W14-9P-LC Specifications

Type	Description
Series:	MIL-DTL-26482 Series II
Package:	Box
Part Status:	Active
Connector Type:	Plug Housing
Type:	For Male Pins
Number of Positions:	9
Shell Size - Insert:	14-9
Shell Size, MIL:	-
Contact Type:	Crimp
Contact Size:	12 (4), 20 (5)
Mounting Type:	Free Hanging (In-Line)
Mounting Feature:	-
Fastening Type:	Bayonet Lock
Orientation:	N (Normal)
Shell Material:	Aluminum
Shell Finish:	Cadmium
Housing Color:	Olive Drab
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
