AE776L24-19S

Part No :: AE776L24-19S

Manufacturer: PEI-Genesis

Description: CONN PLUG FMALE 19POS CRIMP

Catalog: Circular Connectors

DataSheet: AE776L24-19S PDF

Availability: 44 pieces

Current price of AE776L24-19S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE776L24-19S Specifications

Type	Description
Series:	MIL-DTL-26482 Series II
Package:	Box
Part Status:	Active
Connector Type:	Plug, Female Sockets
Number of Positions:	19
Shell Size - Insert:	24-19
Shell Size, MIL:	-
Mounting Type:	Free Hanging (In-Line)
Mounting Feature:	-
Termination:	Crimp
Fastening Type:	Bayonet Lock
Orientation:	N (Normal)
Shell Material:	Aluminum
Shell Finish:	Electroless Nickel
Contact Finish - Mating:	Gold
Color:	-
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
Current Rating (Amps):	23A
Voltage Rating:	1000VDC
Cable Opening:	-
Operating Temperature:	-55°C ~ 200°C
