AE770W22-12S

Part No :: AE770W22-12S

Manufacturer: PEI-Genesis

Description: CONN RCPT FMALE 12POS CRIMP

Catalog: Circular Connectors

DataSheet: AE770W22-12S PDF

Availability: 56 pieces

Unit Price: ~~$59.65000~~

Current price of AE770W22-12S is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AE770W22-12S Specifications

Type	Description
Series:	MIL-DTL-26482 Series II
Package:	Box
Part Status:	Active
Connector Type:	Receptacle, Female Socket
Number of Positions:	12
Shell Size - Insert:	22-12
Shell Size, MIL:	-
Mounting Type:	Panel Mount
Mounting Feature:	Flange
Termination:	Crimp
Fastening Type:	Bayonet Lock
Orientation:	N (Normal)
Shell Material:	Aluminum
Shell Finish:	Olive Drab Cadmium
Contact Finish - Mating:	Gold
Color:	Olive Drab
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	-
Shielding:	Shielded
Current Rating (Amps):	23A
Voltage Rating:	600VDC
Cable Opening:	-
Operating Temperature:	-55°C ~ 175°C
