CA3100E20-27SB09

Part No :: CA3100E20-27SB09

Manufacturer: VEAM

VIGOR # :: 7493046

Description: CONN RCPT FMALE 14P SOLDER CUP

Catalog: Circular Connectors

DataSheet: CA3100E20-27SB09 PDF

Country of origin: -

Date code: -

CA3100E20-27SB09 Specifications

Type	Description
Series:	MIL-DTL-5015, CA-B
Package:	Bulk
Part Status:	Active
Connector Type:	Receptacle, Female Sockets
Number of Positions:	14
Shell Size - Insert:	20-27
Shell Size, MIL:	-
Mounting Type:	Panel Mount, Right Angle
Mounting Feature:	Flange
Termination:	Solder Cup
Fastening Type:	Reverse Bayonet Lock
Orientation:	N (Normal)
Shell Material:	Aluminum Alloy
Shell Finish:	Olive Drab Cadmium
Contact Finish - Mating:	Silver
Color:	Olive Drab
Ingress Protection:	IP67 - Dust Tight, Waterproof
Material Flammability Rating:	-
Features:	Strain Relief
Shielding:	-
Current Rating (Amps):	22A
Voltage Rating:	50V
Cable Opening:	-
Operating Temperature:	-55°C ~ 125°C

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 0

Shipped from

HK warehouse

Expected Shipping Date

Aug 08 - Aug 12 2026

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	~~$80.8400~~	~~$80.84~~
5	~~$73.6390~~	~~$368.20~~
10	~~$65.6350~~	~~$656.35~~
25	~~$62.0328~~	~~$1 550.82~~
50	~~$58.0307~~	~~$2 901.54~~

Current price of CA3100E20-27SB09 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
