CIR01F20A48ST108

Part No :: CIR01F20A48ST108

Manufacturer: VEAM

VIGOR # :: 9401299

Description: CONN RCPT FMALE 19P SOLDER CUP

Catalog: Circular Connectors

DataSheet: CIR01F20A48ST108 PDF

Country of origin: -

Date code: -

CIR01F20A48ST108 Specifications

Type	Description
Series:	CIR
Package:	Bulk
Part Status:	Active
Connector Type:	Receptacle, Female Sockets
Number of Positions:	19
Shell Size - Insert:	20-A48
Shell Size, MIL:	-
Mounting Type:	Free Hanging (In-Line)
Mounting Feature:	-
Termination:	Solder Cup
Fastening Type:	Bayonet Lock
Orientation:	N (Normal)
Shell Material:	Aluminum Alloy
Shell Finish:	Black Zinc Cobalt
Contact Finish - Mating:	Silver
Color:	Black
Ingress Protection:	Environment Proof
Material Flammability Rating:	-
Features:	Cable Clamp
Shielding:	-
Current Rating (Amps):	13A
Voltage Rating:	500VAC, 700VDC
Cable Opening:	-
Operating Temperature:	-55°C ~ 125°C
