TW-34-04-G-D-236-100

Image is for reference,
please contact us to get the real picture

Part No :: TW-34-04-G-D-236-100

Manufacturer: Samtec, Inc.

Description: CONN BRD STACK 2.00 68POS

Catalog: Rectangular Connectors - Board Spacers, Stackers (Board to Board)

DataSheet: TW-34-04-G-D-236-100 PDF

Availability: 59 pieces

Unit Price: ~~$11.91000~~

Current price of TW-34-04-G-D-236-100 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TW-34-04-G-D-236-100 Specifications

Type	Description
Series:	TW
Package:	Bulk
Part Status:	Active
Number of Positions:	68
Pitch:	0.079" (2.00mm)
Number of Rows:	2
Row Spacing:	0.079" (2.00mm)
Length - Overall Pin:	0.555" (14.097mm)
Length - Post (Mating):	0.219" (5.550mm)
Length - Stack Height:	0.236" (5.994mm)
Length - Tail:	0.100" (2.540mm)
Mounting Type:	Through Hole
Termination:	Solder
Contact Finish - Post (Mating):	Gold
Contact Finish Thickness - Post (Mating):	20.0µin (0.51µm)
Color:	Black
