109257016001003

Image is for reference,
please contact us to get the real picture

Part No :: 109257016001003

Manufacturer: Elco (AVX)

Description: CONN PLUG 16POS SOLDER GOLD

Catalog: Rectangular Connectors - Free Hanging, Panel Mount

DataSheet: 109257016001003 PDF

Availability: 3294 pieces

Unit Price: ~~$3.79000~~

Current price of 109257016001003 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

109257016001003 Specifications

Type	Description
Series:	9257
Package:	Bulk
Part Status:	Active
Connector Type:	Plug
Contact Type:	Non-Gender Specific
Number of Positions:	16
Pitch:	0.049" (1.25mm)
Number of Rows:	1
Row Spacing:	-
Mounting Type:	Free Hanging (In-Line)
Fastening Type:	-
Cable Termination:	Solder Cup
Wire Type:	Discrete
Wire Gauge:	-
Features:	-
Contact Finish:	Gold
Contact Finish Thickness:	31.5µin (0.80µm)
Color:	Black

Please confirm the specifications of the products when ordering.
MOQ means the minimum order quantity required to purchase each parts.
If you have special order instructions,please note it on the ordering pages.
The Pre-Shipment Inspection (PSI) will be applied.
You can email us to change the order details before shipment.
Orders cannot be canceled after shipping the packages.

TT in advance (bank transfer), Credit Card, PayPal can be chosen.
Cash transfer only. (Transfer with checks and bills are not accepted.)
Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
If you need the detailed invoice or tax ID,please email us.

FedEx, DHL, and UPS can be selected.
You can select whether to charge shipping fee by your shipping account or to charge by our side.
Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
The shopping cart will automatically calculate the shipping cost.
Delivery time: At the same day (Order deadline is 2pm, HK Time).
Delivery date: usually 2 to 7 working days.
It is unable to appoint a date of delivery.
Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)

In Stock: 3294

Shipped from

HK warehouse

Expected Shipping Date

Nov 18 - Nov 22 2025

Enter Quantity

Pricing(USD)

Quantity	Unit Price	Ext. Price
1	$3.79000	$3.79
10	$3.63840	$36.384
25	$3.33520	$83.38
50	$3.18360	$159.18
100	$3.03200	$303.2
250	$2.65300	$663.25
500	$2.57720	$1288.6
1000	$2.19820	$2198.2
2500	$2.04660	$5116.5
