| Type | Description |
|---|---|
| Series: | DT |
| Package: | Bulk |
| Part Status: | Active |
| Connector Type: | Header |
| Contact Type: | Male Pin |
| Pitch - Mating: | 0.175" (4.44mm) |
| Number of Positions: | 12 |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.360" (9.14mm) |
| Number of Positions Loaded: | All |
| Style: | Board to Cable/Wire |
| Shrouding: | Shrouded - 4 Wall |
| Mounting Type: | Panel Mount, Through Hole |
| Termination: | Solder |
| Fastening Type: | Latch Holder |
| Contact Length - Mating: | - |
| Contact Length - Post: | 0.122" (3.10mm) |
| Overall Contact Length: | - |
| Insulation Height: | 1.371" (34.82mm) |
| Contact Shape: | Circular |
| Contact Finish - Mating: | - |
| Contact Finish Thickness - Mating: | - |
| Contact Finish - Post: | - |
| Contact Material: | - |
| Insulation Material: | Plastic |
| Features: | Mounting Flange |
| Operating Temperature: | -55°C ~ 125°C |
| Ingress Protection: | IP68/IP6K9K |
| Material Flammability Rating: | - |
| Insulation Color: | Black |
| Current Rating (Amps): | - |
| Voltage Rating: | 250VDC |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 10 | ||
| 25 | ||
| 50 | ||
| 100 | ||
| 250 | ||
| 500 | ||
| 1000 |
Current price of DT15-12PB-B016 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
