1SH-A-09-TR-SMT

Image is for reference,
please contact us to get the real picture

Part No :: 1SH-A-09-TR-SMT

Manufacturer: Adam Tech

Description: CONN HEADER SMD R/A 9POS 1MM

Catalog: Rectangular Connectors - Headers, Male Pins

DataSheet: 1SH-A-09-TR-SMT PDF

Availability: 493 pieces

Unit Price: ~~$0.93000~~

Current price of 1SH-A-09-TR-SMT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

1SH-A-09-TR-SMT Specifications

Type	Description
Series:	1SH
Package:	Bulk
Part Status:	Active
Connector Type:	Header
Contact Type:	Male Pin
Pitch - Mating:	0.039" (1.00mm)
Number of Positions:	9
Number of Rows:	1
Row Spacing - Mating:	-
Number of Positions Loaded:	All
Style:	Board to Cable/Wire
Shrouding:	Shrouded - 4 Wall
Mounting Type:	Surface Mount, Right Angle
Termination:	Solder
Fastening Type:	Friction Lock
Contact Length - Mating:	-
Contact Length - Post:	-
Overall Contact Length:	-
Insulation Height:	0.114" (2.90mm)
Contact Shape:	Square
Contact Finish - Mating:	Tin
Contact Finish Thickness - Mating:	-
Contact Finish - Post:	Tin
Contact Material:	Brass
Insulation Material:	Thermoplastic, Glass Filled
Features:	Solder Retention
Operating Temperature:	-25°C ~ 85°C
Ingress Protection:	-
Material Flammability Rating:	UL94 V-0
Insulation Color:	Natural
Current Rating (Amps):	1A
Voltage Rating:	50VAC

Please confirm the specifications of the products when ordering.
