TSW-109-17-S-D

TSW-109-17-S-D

Image is for reference,
please contact us to get the real picture

Part No :

TSW-109-17-S-D

Manufacturer
Samtec, Inc.
Description
CONN HEADER VERT 18POS 2.54MM
Catalog
Rectangular Connectors - Headers, Male Pins
Shipped from
HK warehouse
Expected Shipping Date
Nov 10 - Nov 14 2025
DataSheet
TSW-109-17-S-D PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of TSW-109-17-S-D is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

TSW-109-17-S-D Specifications
Type Description
Series:TSW
Package:Bulk
Part Status:Discontinued at Digi-Key
Connector Type:Header
Contact Type:Male Pin
Pitch - Mating:0.100" (2.54mm)
Number of Positions:18
Number of Rows:2
Row Spacing - Mating:0.100" (2.54mm)
Number of Positions Loaded:All
Style:Board to Board or Cable
Shrouding:Unshrouded
Mounting Type:Through Hole
Termination:Solder
Fastening Type:Push-Pull
Contact Length - Mating:0.620" (15.75mm)
Contact Length - Post:0.110" (2.79mm)
Overall Contact Length:0.830" (21.08mm)
Insulation Height:0.100" (2.54mm)
Contact Shape:Square
Contact Finish - Mating:Gold
Contact Finish Thickness - Mating:30.0µin (0.76µm)
Contact Finish - Post:Tin
Contact Material:Phosphor Bronze
Insulation Material:Polybutylene Terephthalate (PBT)
Features:-
Operating Temperature:-55°C ~ 125°C
Ingress Protection:-
Material Flammability Rating:UL94 V-0
Insulation Color:Black
Current Rating (Amps):-
Voltage Rating:-
