| Type | Description |
|---|---|
| Series: | Gecko SL |
| Package: | Cut Tape (CT) |
| Part Status: | Active |
| Connector Type: | Receptacle |
| Contact Type: | Female Socket |
| Style: | Board to Board or Cable |
| Number of Positions: | 26 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.049" (1.25mm) |
| Number of Rows: | 2 |
| Row Spacing - Mating: | 0.049" (1.25mm) |
| Mounting Type: | Through Hole |
| Termination: | Solder |
| Fastening Type: | Screw Lock |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | 8.00µin (0.203µm) |
| Insulation Color: | Green |
| Insulation Height: | 0.207" (5.25mm) |
| Contact Length - Post: | 0.118" (3.00mm) |
| Operating Temperature: | -65°C ~ 150°C |
| Material Flammability Rating: | UL94 V-0 |
| Contact Finish - Post: | Gold |
| Mated Stacking Heights: | 7.25mm, 7.33mm |
| Ingress Protection: | - |
| Features: | Jackscrews, Pick and Place, Polarizing Key |
| Current Rating (Amps): | 2A |
| Voltage Rating: | 450V |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 10 | ||
| 100 |
Current price of G125-FV12605F3P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
