| Type | Description |
|---|---|
| Series: | Archer M50 |
| Package: | Tape & Reel (TR)Cut Tape (CT) |
| Part Status: | Active |
| Connector Type: | Receptacle, Bottom or Top Entry |
| Contact Type: | Female Socket |
| Style: | Board to Board |
| Number of Positions: | 8 |
| Number of Positions Loaded: | All |
| Pitch - Mating: | 0.050" (1.27mm) |
| Number of Rows: | 1 |
| Row Spacing - Mating: | - |
| Mounting Type: | Surface Mount |
| Termination: | Solder |
| Fastening Type: | Push-Pull |
| Contact Finish - Mating: | Gold |
| Contact Finish Thickness - Mating: | 12.0µin (0.30µm) |
| Insulation Color: | Black |
| Insulation Height: | 0.079" (2.00mm) |
| Contact Length - Post: | - |
| Operating Temperature: | -40°C ~ 105°C |
| Material Flammability Rating: | UL94 V-0 |
| Contact Finish - Post: | Gold |
| Mated Stacking Heights: | 3.1mm, 3.6mm, 3.8mm |
| Ingress Protection: | - |
| Features: | Pick and Place |
| Current Rating (Amps): | 1A |
| Voltage Rating: | 500VAC |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 2000 | ||
| 4000 | ||
| 6000 | ||
| 10000 | ||
| 14000 |
Current price of M50-3130845R is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
